Trek Checkpoint SL 2022 geometry

Size chart for fitting. If this bike already feels right, find others with a similar riding position (size 49). Category: gravel.

Size	Stack	Reach	Head tube angle	Seat tube angle	Chainstay	Wheelbase	BB drop
49	554 mm	375 mm	71.0°	74.0°	430 mm	1029 mm	74 mm
52	574 mm	382 mm	71.4°	73.7°	430 mm	1039 mm	74 mm
54	591 mm	388 mm	71.6°	73.4°	430 mm	1049 mm	72 mm
56	609 mm	394 mm	71.8°	73.2°	430 mm	1059 mm	72 mm
58	629 mm	400 mm	72.0°	73.0°	432 mm	1071 mm	70 mm
61	651 mm	406 mm	72.2°	72.8°	432 mm	1084 mm	70 mm
L	619 mm	401 mm	72.1°	73.0°	430 mm	1051 mm	76 mm
M	578 mm	390 mm	71.6°	73.4°	430 mm	1033 mm	76 mm
ML	600 mm	396 mm	72.0°	73.2°	430 mm	1041 mm	76 mm
S	555 mm	385 mm	71.4°	73.7°	430 mm	1021 mm	76 mm
XL	639 mm	407 mm	72.4°	72.8°	430 mm	1061 mm	76 mm
XS	534 mm	379 mm	71.0°	74.0°	430 mm	1012 mm	76 mm

Similar bikes

Closest matches to this riding position — free, no login.

Size guidance

Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
