Trek Procaliber 2022 geometry
Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: mtb-xc.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| L | 623 mm | 449 mm | 68.8° | 74.0° | 430 mm | 1153 mm | 58 mm |
| M | 610 mm | 419 mm | 68.8° | 74.0° | 430 mm | 1119 mm | 58 mm |
| ML | 614 mm | 434 mm | 68.8° | 74.0° | 430 mm | 1134 mm | 58 mm |
| S | 606 mm | 394 mm | 68.8° | 74.0° | 430 mm | 1094 mm | 58 mm |
| XL | 642 mm | 474 mm | 68.8° | 74.0° | 430 mm | 1187 mm | 58 mm |
Similar bikes
Closest matches to this riding position — free, no login.
Size guidance
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
