Specialized Diverge 2022 geometry
Size chart for fitting. If this bike already feels right, find others with a similar riding position (size 49). Category: gravel.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| 49 | 559 mm | 369 mm | 70.0° | 74.0° | 425 mm | 1024 mm | 80 mm |
| 52 | 577 mm | 376 mm | 70.5° | 73.7° | 425 mm | 1034 mm | 80 mm |
| 54 | 594 mm | 382 mm | 71.0° | 73.5° | 425 mm | 1044 mm | 78 mm |
| 56 | 611 mm | 389 mm | 71.5° | 73.2° | 425 mm | 1054 mm | 78 mm |
| 58 | 631 mm | 396 mm | 71.5° | 73.0° | 428 mm | 1067 mm | 76 mm |
| 61 | 654 mm | 403 mm | 72.0° | 72.8° | 428 mm | 1081 mm | 76 mm |
Similar bikes
Closest matches to this riding position — free, no login.
- Specialized S-Works Diverge 2022Size 49 · 559 mm / 369 mm
- Specialized S-Works Diverge 2023Size 49 · 559 mm / 370 mm
- Specialized S-Works Diverge 2024Size 49 · 560 mm / 370 mm
- Specialized S-Works Diverge 2025Size 49 · 560 mm / 370 mm
Size guidance
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
