BMC URS 2022 geometry
Size chart for fitting. If this bike already feels right, find others with a similar riding position (size L). Category: gravel.
| Size | Stack | Reach | Head tube angle | Seat tube angle | Chainstay | Wheelbase | BB drop |
|---|---|---|---|---|---|---|---|
| L | 599 mm | 399 mm | 71.0° | 73.5° | 435 mm | 1067 mm | 76 mm |
| M | 579 mm | 389 mm | 70.5° | 73.5° | 435 mm | 1053 mm | 78 mm |
| S | 559 mm | 379 mm | 70.0° | 74.0° | 435 mm | 1039 mm | 78 mm |
| XL | 619 mm | 409 mm | 71.0° | 73.0° | 435 mm | 1083 mm | 76 mm |
Similar bikes
Closest matches to this riding position — free, no login.
Size guidance
Stack and reach describe the frame's cockpit envelope better than traditional seat-tube sizing. If you know your preferred stack/reach from a bike that already fits, search within a few millimeters first, then check head angle and chainstay for handling feel. See the glossary for stack, reach, and HTA.
